Series
A-Series
B-Series
C-Series
D-Series
E-Series
Max Engine Size (Liters)
9
18
30
41
100
Torque (Ft-Lbs)
15
45
72
120
200
Displacement (in³/REV)
0.5
1.35
2
3.5
5.88
Starter Weight (Lbs)
11
17
35
40
46
E-SERIES (CMD-3A)
The starter of choice by engine OEMs, the E-series repeatedly produces 200 ft-lb of torque. It weighs significantly less than other gear motor-driven starters at 46 lbs and provides more power per pound. The E-Series can be found in applications including frac pumps, emergency gen-sets, and fire pumps on offshore platforms. The E-series can start an engine up to 100 liters (6100 cu. in.). E-Series Models: E1-11C2200-30200, E1-12C2200-3R200, E1-12C2200-3L200, E1-12C2200-30200
D-SERIES (CMD-3A)
This model convincingly produces 120 ft-lbs of torque in only a 40 lb package. D-series starters are common in numerous applications, including fire pumps, gensets, and frac pumps. This starter model dependably starts engines up to a 41-liter displacement (2500 cu. in.). D-Series Models: D1-12C2200-3L200, D1-12C2200-3R200, D1-12C2200-30173, D1-12C2200-30200
C-SERIES (CMD-2A)
The C-series starter fits a vast array of engines with some overlap on both the low and high ends. This model features 72 ft-lbs of torque in only a 35 lb product commonly used in applications, including blenders, gen-sets, and pumping engines. C-Series Models: C1-11C2200-30173, C1-11C2200-30200, C1-12D2150-30200
B - SERIES (CMA)
The B-series is commonly relied upon for dependability, starting with the combination of torque and modularity. The B-series starter is a workhorse providing 45 ft-lbs of torque in a 17 lb package. Depending on conditions, the starter cranks up to 18 liter (1098 cu. in.) engines which are common in the marine industry. B-Series Models: B1-09B1106-1A200, B1-09D2113-1A200, B1-10D2125-1A200, B1-10E2100-1A200, B1-11B1130-1A200, B1-11C2183-3A200, B1-12D2150-3A200, B2-10D2125-1A200, B2-12C2200-3A200
A-SERIES (CMO)
The A-series is not to be underestimated. Although small and extremely light (11 lbs), this starter packs a punch with 15 ft-lbs of torque and the ability to turn at 7000 RPM. This translates into a high-speed engine starting up to 9 liters (549 cu. in.). These smaller engines are common on lifeboats, a prime example of when fast starting is paramount. A-Series Models: A1-09B1106-TJ096, A1-09B1106-TR114-K, A1-12D2150-1A200, A1-12D2150-3A200, A1-13A1128-T0094
